Taconic TLX-7 High Frequency PCB (2-Layer, 0.6mm) is a precision-engineered RF PCB featuring an Immersion Silver finish. This PTFE fiberglass laminate is designed for extreme-environment RF/microwave applications. With its ultra-slim 0.6mm profile, it delivers exceptional signal integrity for high-frequency designs, guaranteeing reliability in aerospace, defense, and 5G systems.
It provides unparalleled resistance to vibration, radiation, and thermal stress while maintaining ultra-low PIM (< -160 dBc).
What makes the Taconic TLX-7 material suitable for aerospace?
It offers NASA-grade outgassing (TML 0.02%), resistance to space radiation, and exceptional stability under extreme launch vibrations and thermal stress.
What is the dielectric constant (Dk) of this PCB?
The TLX-7 substrate provides an ultra-stable Dk of 2.6 ± 0.04 at 10GHz, ensuring precise signal timing.
Does this board support high-frequency 5G applications?
Yes, its low dissipation factor (Df 0.0014 @1.9GHz) and ultra-low PIM performance make it ideal for 5G massive MIMO antennas and infrastructure.
What surface finish is applied to this RF PCB?
This specific design utilizes an Immersion Silver finish, which is excellent for high-frequency signal integrity and flat surface requirements.
How is the quality of the boards verified before shipping?
Every board undergoes 100% electrical testing and is manufactured to IPC-Class-2 standards to ensure mission-critical reliability.
Can I get a custom thickness for this PTFE laminate?
While this reference model is 0.6mm, all PCBs are custom-manufactured based on your specific design requirements and stackup needs.
